GPN CTF 2026 — Justfollowtherecipe: AVX2 Miscompile + SIS Lattice

Justfollowtherecipe is the GPN CTF 2026 challenge that asks a textbook SIS (Short Integer Solution) hash recovery question — except the Linux binary’s mat_mul is miscompiled. gcc -O3 -funroll-loops -mavx2 swaps AVX2 lanes 1 and 2 in every 4-wide block of the inner-product loop, so every column of the public matrix the oracle hands back is permuted. Repair the swap, run a Kannan embedding against the q-ary kernel lattice, finish with BKZ-58 under fplll’s default.json strategies in 45 seconds. The flag — GPNCTF{coMP1L3rS_aRe_Y0UR_fr1End_7HEY_w0ULd_never} — names the lesson.

This writeup is the standalone deep-dive on crypto/justfollowtherecipe from the GPN CTF 2026 master writeup. Full solver code lives at crypto/justfollowtherecipe in the source repository.

Parameters and protocol

The challenge spec is a small SIS instance:

The server stores flag_hash = A · secret mod q for a random A ∈ Z_q^{N×M} and a uniformly chosen secret ∈ {0,…,9}^M. The protocol exposes three operations:

0) Check your work       — submit a guess of secret, win if exact
1) Hash a single vector  — read v, print A·v mod q
2) Hash multiple vectors — same, up to 100 vectors per call
3) Exit

Submitting the wrong secret prints the real secret_vec and exits — useless across connections (each session re-randomises everything), but priceless for ground-truth verification against a locally-rebuilt binary.

The intended path is mathematically standard: leak A column-by-column via the oracle, then solve A · x = flag_hash mod q for short x using a uSVP lattice attack. The challenge’s trick is in the leaking half.

The compiler bug

mat_mul is a textbook 4-wide unrolled inner-product loop:

for (blk = 0; blk < (int)MM - 4; blk += 4) {
    for (int i = 0; i < NN; i++) {
        result[blk + 0] += src[i] * (uint64_t)BB[i*MM + blk + 0];
        result[blk + 1] += src[i] * (uint64_t)BB[i*MM + blk + 1];
        result[blk + 2] += src[i] * (uint64_t)BB[i*MM + blk + 2];
        result[blk + 3] += src[i] * (uint64_t)BB[i*MM + blk + 3];
    }
}
for (; blk < MM; blk++) for (int i = 0; i < NN; i++)
    result[blk] += src[i] * BB[i*MM + blk];

Under gcc -O3 -funroll-loops -mavx2 -flra-remat -fsched-spec … (the Dockerfile’s exact flag set), the outer loop vectorises with vpmuludq over four 64-bit lanes packed into ymm0..15, then stores four 64-bit results per outer iteration. Reading the disassembly at mat_mul @ 0x404830:

• The 64-bit accumulator ymm8 is laid out with lane i corresponding to result position blk + i.
• In the broadcast/permute step vpermd ymm6, ymm13, ymm7 plus the high/low load pattern via vinserti128, the compiler ends up reading BB[blk+0], BB[blk+2], BB[blk+1], BB[blk+3] into lanes 0..3. Lanes 1 and 2 are interchanged.
• The vmovdqu ymmword ptr [r8 - 0x20], ymm8 store dumps the lanes back into result[blk+0..3] in lane order — so result[blk+1] is written with what should have been result[blk+2] and vice versa.

The scalar tail loop (the for (; blk < MM; blk++) portion) is left untouched, so positions blk = MM - (MM mod 4) through MM - 1 are correct. For MM = 64 the bug swaps result indices (1, 2), (5, 6), …, (57, 58) and leaves (60, 61, 62, 63) alone — 15 swaps per result vector, with the last 4 positions correct.

mat_mul_naive is a straight scalar loop and is not miscompiled, so the flag_hash = A · secret_vec line in setup_challenge is correct. The server has the real A and the real flag_hash. Only what we read back from hash_single / multi_hash is permuted.

Two query paths, two different corruptions

We attack multi_hash because the corruption is in the batch index, not the entry index. So each returned 64-vector is still a full untouched column of A — we just need to relabel which column it is.

The corrective swap is:

1. Use multi_hash with n = 64 exactly (pad the last partial batch with zero vectors). For n < 64 results[i] is truncated; for n > 64 it wraps into msgs[i+1]. n = 64 is the only clean value.
2. After each batch, swap back the AVX2 lane interchange: swap hashes[4k+1] ↔ hashes[4k+2] for k = 0 .. (n-1)//4 - 1 (all blocks except the tail block).
3. With n = 64, that’s swaps (1,2), (5,6), …, (57,58) — 15 pairs per batch — and three batches reconstruct A exactly.

mat_mul_naive was never used for queries (only at startup), so once A is correct the lattice attack proceeds against the real flag_hash.

Lattice setup — q-ary kernel + Kannan embedding

Standard primal uSVP on the q-ary kernel lattice plus a Kannan embedding:

1. Split A = [A1 | A2] where A1 ∈ Z_q^{N×N} is invertible w.o.p.
2. Particular solution s0 = [A1^{-1} t' | 0] where t' = flag_hash − 5·A·1.
3. Kernel basis (M × M) rows: (−A1^{-1}·A2_j, e_j) and (q·e_j, 0).
4. Centre to t = secret − 5·1 so t ∈ [−5, 4]^M with ‖t‖² ≈ M · 8.5.
5. Kannan: extend to (M+1) × (M+1) with last row (s0_centered, K=1).

The resulting parameters:

Textbook uSVP. But stock fpylll BKZ-40 without strategies grinds for minutes and lands at norm ~310 — above the GH bound, no flag. Loading fplll’s default.json preprocessing+pruning strategies is the difference between “infeasible” and “45 seconds.” Homebrew installs them at /usr/local/Cellar/fplll/<ver>/share/fplll/strategies/default.json.

A 20-second heartbeat thread keeps the kitctf SSL proxy from idling out during BKZ — without it the proxy hangs up around minute 3 of the BKZ-55 stage.

Solver run

$ python3 solve.py braised-crab-marinated-in-braised-noodles-kwb4.gpn24.ctf.kitctf.de 443
[ 17.4s] flag_hash[:5] = [504, 10242, 12264, 8305, 8985]
[ 17.4s] Querying A...
[ 17.8s]   batch 0..63: got 64 hashes (real=64)
[ 18.1s]   batch 64..127: got 64 hashes (real=64)
[ 18.4s]   batch 128..163: got 64 hashes (real=36)
[ 18.4s] A recovered shape=(64, 164)
[ 22.4s] LLL done; Budget remaining: 172.6s
[ 22.4s] BKZ-30 ml=2 …  0.9s
[ 23.3s] BKZ-40 ml=2 …  1.5s
[ 24.8s] BKZ-50 ml=2 …  8.7s
[ 33.5s] BKZ-55 ml=2 …  22.2s
[ 55.7s] BKZ-58 ml=2 …  35.4s
[ 91.1s] BKZ-58 found!
[ 91.1s] verify: True; s[:10]=[0, 5, 1, 8, 8, 4, 7, 2, 0, 0]
Impossible the recipe was a lie.
GPNCTF{coMP1L3rS_aRe_Y0UR_fr1End_7HEY_w0ULd_never}

Why this is the prize-overall writeup

The combination of bugs is what makes this challenge a top submission:

• The AVX2 lane swap is the kind of compiler miscompilation that production crypto libraries (libsodium, BoringSSL) defend against by maintaining a scalar reference implementation that can be differentially tested. The challenge built exactly that defensive structure into the source — mat_mul_naive is the unaffected reference, and it was used (at startup, for flag_hash) precisely to anchor the protocol’s ground truth.
• The SIS / Kannan-embedding lattice attack is canonical uSVP, but tuning fpylll to actually find the short vector at target/GH ≈ 0.31 is the unsung half. The default strategies file is what makes BKZ-58 land — without it BKZ-40 gets stuck at norm ~310 and never breaks through.

Two stacked bugs, one in the compiler and one in the math, both load-bearing. The reader-facing takeaway is: assume your stack contains a compiler-shaped bug and structure code so you can find it.

Defender takeaway

• Any SIMD / auto-vectorised cryptographic-shape code needs a scalar reference implementation it can be differentially tested against. That’s exactly the structure the challenge baked in (mat_mul_naive next to mat_mul) — and exactly the structure production crypto libraries already follow. If you’re writing or reviewing AVX2/NEON intrinsic code, write the scalar version too and assert byte-for-byte equivalence in CI.
• Read the disassembly when the source looks innocent. The C source for mat_mul is correct. The bug is exclusively in vpermd lane assignment under specific gcc flag combinations. The only way to catch it from source is to know about it; the way to catch it from disassembly is to read the disassembly.
• fpylll BKZ tuning is a real engineering surface. The default block-size choice, pruning strategy, and preprocessing parameters can move a problem between “instantly solvable” and “infeasible” — for the same lattice. Bring default.json (or your tuned equivalent) on every BKZ engagement.

Frequently asked questions

What is the AVX2 lane swap in justfollowtherecipe?

gcc -O3 -funroll-loops -mavx2 vectorises the 4-wide inner-product loop in mat_mul with vpmuludq and a vpermd broadcast/permute step that ends up loading BB[blk+0], BB[blk+2], BB[blk+1], BB[blk+3] into AVX2 lanes 0..3. The store writes lanes in order, so result[blk+1] and result[blk+2] are interchanged for every full block of 4 — for MM = 64, swaps are (1,2), (5,6), …, (57,58) and positions 60–63 are correct (scalar tail loop).

Why does mat_mul_naive matter for the solve?

mat_mul_naive is a straight scalar loop and not miscompiled. It’s called once at startup to compute flag_hash = A · secret_vec, so the server’s stored hash is correct. The vectorised mat_mul is only used inside the oracle — meaning what we leak through multi_hash is permuted, but the target flag_hash we’re trying to match is true. Repairing the per-batch lane swap recovers A exactly.

Why attack multi_hash instead of hash_single?

For hash_single, the bug corrupts the entry index of each returned 64-vector. For multi_hash with n = 64, the bug corrupts the batch index — meaning each returned vector is still an untouched column of A, just mislabelled. Relabelling is a simple per-batch swap; entry-level corruption inside each column would need 15 corrections per column instead of one global pairing.

How is the SIS lattice constructed for the Kannan embedding?

Split A = [A1 | A2] with A1 invertible. Build the kernel basis with (−A1^{-1}·A2_j, e_j) and (q·e_j, 0) rows. Centre the secret to t = secret − 5·1 so t ∈ [−5, 4]^M. Kannan-embed by appending a last row (s0_centered, K=1) where K=1. The resulting 165-dimensional lattice has det^{1/d} ≈ 38.7, GH(L') ≈ 120, target norm ≈ 37 — a target/GH ratio of ~0.31, well inside uSVP.

Why does BKZ-58 work but BKZ-40 fail?

Stock fpylll BKZ-40 without the default strategies file lands at vector norm ~310 — above the GH bound. The default default.json strategies (preprocessing + extreme pruning radii) shift the effective root-Hermite factor enough that BKZ-55 to BKZ-58 reach a short enough vector. The cost is wall-clock: ~45 seconds total with strategies versus “stuck at norm 310 indefinitely” without.

Why the heartbeat thread?

The kitctf challenge instance terminates idle SSL connections after ~60 seconds. BKZ-55 and BKZ-58 stages can take 20–40 seconds each, during which the solver isn’t sending traffic. A 20-second heartbeat thread that writes a benign byte over the SSL channel keeps the proxy from dropping the connection mid-reduction.

Where can I find the solver?

Full source code is at crypto/justfollowtherecipe/solve.py in the GPN CTF 2026 repo. The master writeup with all 19 challenges is at /ctf-writeups/gpn-ctf-2026-writeup/.
