GPN CTF 2026 — Organized: Ternary Amplitude-Modulated UART in Popcount Density

Organized is the GPN CTF 2026 misc challenge whose entire trick is recognising the carrier’s organization. The handout is a 7,650,000-byte file that looks like noise — file(1) calls it data, every bit position is 1 with probability ≈ 0.287. The “organization” is hidden in the bit-density of windows, not in the bytes themselves: per-12,500-byte window popcount falls into one of three sharp levels, giving a 612-trit string. Past a 24-trit preamble, the rest is 49 UART-style frames of 12 trits each. Decode → ASCII → flag:

GPNCTF{tHaNK_YOU_tO_entropia_FoR_Or64niZ1N6_GPN!}

The flag thanks Entropia e.V. for organizing GPN — fitting payoff for a challenge that’s about recognising organization in noise. This is the standalone deep-dive on misc/organized from the GPN CTF 2026 master writeup. Full source at misc/organized.

Recon

$ wc -c data
 7650000 data
$ file data
data: data

7,650,000 = 2⁴ · 3² · 5⁵ · 17 — no clean image dimensions. Byte-value frequencies are very uneven:

popcount=0  (byte 0x00):           1,573,858   ← way over uniform (29,883)
popcount=1  (8 single-bit bytes):  ~214,900 each
popcount=2  (28 two-bit bytes):    ~42,400 each
popcount=8  (byte 0xFF):           12,681       ← way under uniform

The 8 bit positions are each set with density ≈ 0.287, but the 0x00 byte is over-represented 3×. So the bits are positively correlated — when one bit in a byte is 0, others tend to be 0 too. That’s the smoking gun: the file has slowly-varying bit-density across positions.

Spotting the carrier

Renders of data as a 1-bpp bitmap at every plausible width all show horizontal stripes — the row-to-row popcount oscillates. So look at popcount averaged in fixed windows:

import numpy as np
d   = np.frombuffer(open("data","rb").read(), dtype=np.uint8)
pop = np.unpackbits(d).reshape(-1, 8).sum(1)
avg = pop.reshape(-1, 100).mean(1)               # 76,500 windows of 100 bytes
classes = (avg > 2).astype(int)

Run-length the binary class signal — every run is a multiple of 125 windows = 12,500 bytes:

len  125: 188 runs
len  250:  45
len  375:  48
len  500:  25
len  625:  12
len  750:   1
len  875:   3

The carrier has a fixed block size of 12,500 bytes per symbol, and 7,650,000 / 12,500 = 612 blocks total.

Three levels, not two

Recomputing the popcount means per 12,500-byte block at full precision:

Three sharp peaks, nothing else — confirmed by a 200-bin histogram. The file is amplitude-modulated in three steps. Map by rounding the mean to the nearest multiple of 0.8 ({1, 2, 5} → {0, 1, 2}) and you get a 612-character ternary string.

Reading the ternary stream

First 80 trits:

000222000222002020002200 102220002021100000202021100222002021102200002021
└───── preamble ───────┘ └─ frame ──┘└─ frame ──┘└─ frame ──┘└─ frame ──┘

Past the 24-trit preamble, slice in widths of 12. Every single 12-trit slice satisfies:

• trit 0 and trit 11 are 1 (mid-level idle markers)
• trits 1..10 are only 0 or 2

That’s 49 frames after a header. The mid-level 1 appears exactly 98 times in the whole file — 49 frames × 2 boundary markers — and nowhere else. The carrier is using its mid amplitude as an inter-frame idle / break signal.

Within a frame, the natural reading is UART: start bit, 8 data bits LSB-first, stop bit, framed by idle. Mapping 0 → bit 0, 2 → bit 1, trits 2..9 are the byte (LSB-first):

frame "1 0 2 2 2 0 0 0 2 0 2 1"  →  data trits "2 2 2 0 0 0 2 0"
                                  →  bits LSB→MSB  1 1 1 0 0 0 1 0
                                  →  byte 0x47  =  'G'

That’s the ‘G’ of GPNCTF{. Repeat for all 49 frames and the flag falls out.

Solver

import numpy as np

d = np.frombuffer(open("data","rb").read(), dtype=np.uint8)
pop = np.unpackbits(d).reshape(-1, 8).sum(1)
per_block = pop.reshape(-1, 12_500).mean(1)
syms = "".join({1:"0", 2:"1", 5:"2"}[x]
               for x in np.round(per_block / 0.8).astype(int))

frames = syms[24:]                                   # drop 24-trit preamble
flag = "".join(
    chr(int("".join("1" if c=="2" else "0" for c in frames[i+2:i+10])[::-1], 2))
    for i in range(0, len(frames), 12)
)
print(flag)

$ python3 solve.py data
GPNCTF{tHaNK_YOU_tO_entropia_FoR_Or64niZ1N6_GPN!}

The preamble

The 24-trit preamble (000222000222002020002200) sits before the first frame and is not framed by 1 idle markers. As bits it spells the three bytes 1c 72 8c — not text. Most likely a synchronisation pre-roll: enough alternation between low and high amplitudes for a receiver to lock onto the symbol rate before the framed UART stream starts. The decoder doesn’t need it; just skip 24 trits.

Why this challenge teaches a real lesson

The default reading of “high-entropy file” is “encrypted data.” The second-default is “compressed data.” Both are wrong here — the carrier is not uniform random; it’s three-amplitude-modulated, and the modulation is invisible at the byte level. Reading the popcount density at the right window size is the entire diagnosis.

The discovery path that worked, in three steps:

1. “Is this image data?” — render 25 candidate widths at 1 bpp. All show horizontal stripes. Not an image.
2. “What’s the smallest periodic structure in popcount?” — compute per-window popcount means and run-lengths. Every run is a multiple of 125 windows = 12,500 bytes.
3. “Three peaks or two?” — 200-bin histogram of per-block popcount. Three clear peaks. Ternary.

Each step rules out a hypothesis; nothing is brute-forced. By the time the third step lands, the carrier structure is fully recovered and the UART framing is the only natural reading.

Defender takeaway

The lesson is generic across DFIR and reverse engineering: don’t anchor on the first hypothesis. A file that looks like noise to file(1) and to byte-frequency analysis can still carry structured information at a window scale that neither tool examines. Tools that compute window statistics — binwalk -E for entropy, custom popcount-per-window scripts — are the first line of defence against this class of bug.

The class is broader than CTFs. Side-channel exfiltration via cache-line popcount, USB power-line modulation, fan-speed-encoded covert channels — all reduce to the same recognition problem: “what’s the carrier’s smallest periodic structure, and what alphabet does it speak?”

Frequently asked questions

Why is the file 7,650,000 bytes?

7,650,000 = 612 × 12,500. The carrier is 612 ternary symbols, each encoded as 12,500 bytes of amplitude-modulated data. The factorisation 2⁴ · 3² · 5⁵ · 17 rules out common image dimensions (no clean width/height pair), which is the first hint that the file isn’t a bitmap.

Why does file(1) say data?

The file has no magic bytes and high byte-entropy (~7.x bits/byte). file(1) falls back to its catch-all data classification when no recognisable format matches. The bytes look uniformly distributed at first glance — but their bit-density per window is correlated, which file(1) does not check.

How do you spot the three amplitude levels?

Plot a 200-bin histogram of per-12,500-byte-window popcount means. Three sharp peaks at means 0.795, 1.60, 4.00 (densities 0.099, 0.200, 0.500). The middle peak is much rarer (98 windows) than the outer two (252, 262) — that’s the giveaway that the middle level is special (idle/break marker), not equiprobable.

Why UART specifically?

The framing is 1 0_or_2_×8 1 — the mid-level idle marker, eight 0-or-2 data trits (binary in disguise), the mid-level idle marker. That’s exactly UART’s start-stop framing with the data bits LSB-first. The choice of “ternary amplitude with the middle as idle” is a clever way to embed a binary UART stream in a ternary symbol space — the idle marker carries no data but signals frame boundaries.

What is the 24-trit preamble?

000222000222002020002200 — three bytes (1c 72 8c) that aren’t ASCII. Most likely a synchronisation pre-roll giving the receiver enough amplitude alternation to lock onto the symbol rate before the framed stream starts. Real UART transmitters use a similar BREAK signal followed by an idle pattern. Decoder doesn’t need it; skip 24 trits.

What’s the broader pattern for “high-entropy” files in CTFs?

Don’t anchor on “encrypted.” Compute window statistics — binwalk -E for entropy, custom popcount-per-window scripts, FFT of per-window means for periodic carriers. Window size guesses: 100, 1000, 12500, 65536 bytes. Plot histograms of window statistics; look for peaks. If three or more peaks emerge cleanly, the file is amplitude-modulated, not encrypted.

Where can I find the solver?

Full source at misc/organized/solve.py. Master writeup at /ctf-writeups/gpn-ctf-2026-writeup/.
